DDR4 5133(OC)/5000(OC)/4800(OC)/4700(OC)/4600(OC)/4500(OC)/4400(OC) /4266(OC)/4133(OC)/4000(OC)/3866(OC)/3733(OC)/3600(OC)/3466(OC)/3400(OC)/3333(OC)/3200/3000/2933/2800/2666/2400/2133 مگاهرتز

17 فاز

Intel Socket LGA1200 for 11th Gen Intel Core Processors & 10th Gen Intel Core, Pentium Gold and Celeron Processors\r\nSupports Intel 14 nm CPU\r\nSupports Intel Turbo Boost Technology 2.0 and Intel Turbo Boost Max Technology 3.0\r\nIntel Turbo Boost Max Technology 3.0 support depends on the CPU types

یک عدد کومبو

20 مسیر

1 عدد

DDR4 5133(OC)/5000(OC)/4800(OC)/4700(OC)/4600(OC)/4500(OC)/4400(OC) /4266(OC)/4133(OC)/4000(OC)/3866(OC)/3733(OC)/3600(OC)/3466(OC)/3400(OC)/3333(OC)/3200/3000/2933/2800/2666/2400/2133 MHz Non-ECC, Un-buffered Memory

1 عدد USB 3.2 Gen 2x2 port (1 x USB Type-C)\r\n2 عدد USB 3.2 Gen 2 ports (2 x Type-A)\r\n2 عدد USB 3.2 Gen 1 ports (2 x Type-A)\r\n2 عدد USB 2.0 ports (2 x Type-A)\r\n1 عدد DisplayPort\r\n1 عدد HDMI port\r\n1 عدد ASUS Wi-Fi Module\r\n1 عدد Intel I225-V 2.5Gb Ethernet port\r\n5 عدد Audio jacks\r\n1 عدد Optical S/PDIF out port\r\n1 عدد PS/2 Keyboard/Mouse combo port

پنل پشتی (مجموعا 7 پورت):\r\n - 1 عدد USB 3.2 Gen 2x2 port (1 x USB Type-C)\r\n - 2 عدد USB 3.2 Gen 2 ports (2 x Type-A)\r\n - 2 عدد USB 3.2 Gen 1 ports (2 x Type-A)\r\n - 2 عدد USB 2.0 ports (2 x Type-A)\r\nاتصالات داخلی (مجموعا 7 پورت):\r\n - 1 عدد USB 3.2 Gen 1 connector (suppports USB Type-C)\r\n - 1 عدد USB 3.2 Gen 1 header supports additional 2 USB 3.2 Gen 1 ports\r\n - 2 عدد USB 2.0 headers support additional 4 USB 2.0 ports

پشتیبانی از 3 عدد M.2 slot\r\nTotal supports 3 x M.2 slots and 6 x SATA 6Gb/s ports\r\nIntel11th Gen Processors\r\nM.2_1 slot (Key M), type 2242/2260/2280/22110\r\n- Only Intel 11th processors support PCIe 4.0 x4 mode, this slot will be disabled for other CPUs\r\nIntel Z590 Chipset\r\nM.2_2 slot (Key M), type 2242/2260/2280/22110 (supports PCIe 3.0 x4 & SATA modes)\r\nM.2_3 slot (Key M), type 2242/2260/2280 (supports PCIe 3.0 x4 & SATA modes)\r\n6 عدد SATA 6Gb/s ports\r\nRaid function for PCIe mode SSD in Intel Rapid Storage Technology is available with either 1. Intel SSDs installed in both CPU-attached and PCH-attached slots, or 2. any other 3rd party SSDs installed in PCH-attached slots.\r\nTo enable Intel Optane Memory (Hybrid Storage device), it must be installed in PCH-attached slots with Intel Rapid Storage Technology\r\nM.2_2 shares bandwidth with SATA6G_2. When M.2_2 runs SATA mode, SATA6G_2 will be disabled\r\nM.2_3 shares bandwidth with SATA6G_56. When M.2_3 is occupied, SATA6G_56 will be disabled

1 عدد Thunderbolt header\r\n1 عدد Front Panel Audio header (AAFP)\r\n1 عدد COM Port header\r\n1 عدد Clear CMOS header\r\n2 عدد AURA RGB headers\r\n2 عدد AURA Addressable Gen 2 headers\r\n1 عدد USB 3.2 Gen 1 connector (supports USB Type-C®)\r\n1 عدد USB 3.2 Gen 1 headers supports additional 2 USB 3.2 Gen 1 ports\r\n2 عدد USB 2.0 headers support additional 4 USB 2.0 ports\r\n6 عدد SATA 6Gb/s ports\r\n3 عدد M.2 slots (Key M)

Realtek ALC S1200A 7.1 Surround Sound High Definition Audio CODEC\r\n - پشتیبانی از : Jack-detection, Multi-streaming, Front Panel Jack-retasking\r\n - پشتیبانی تا 24-Bit/192 kHz playback\r\nویژگی‌های کارت صدا:\r\n - Audio Shielding\r\n - Rear optical S/PDIF out port\r\n - Premium Japanese audio capacitors\r\n - Dedicated audio PCB layers\r\n - Audio cover

5 عدد

DDR4 5133(OC)/5000(OC)/4800(OC)/4700(OC)/4600(OC)/4500(OC)/4400(OC) /4266(OC)/4133(OC)/4000(OC)/3866(OC)/3733(OC)/3600(OC)/3466(OC)/3400(OC)/3333(OC)/3200/3000/2933/2800/2666/2400/2133 MHz Non-ECC, Un-buffered Memory\r\nDual Channel Memory Architecture\r\nSupports Intel Extreme Memory Profile (XMP)\r\nOptiMem II\r\n10th Gen Intel Core i7/i9 processors support 2933/2800/2666/2400/2133 natively, others will run at the maximum transfer rate of DDR4 2666MHz\r\n11th Gen Intel processors support 3200/2933/2800/2666/2400/2133 natively

128 گیگابایت

192Mb (128+64) Flash ROM, UEFI AMI BIOS

1 عدد DP1.4\r\n1 عدد HDMITM 2.0\r\nGraphics specifications may vary between CPU types\r\nIntel 11th & 10th processors support DisplayPort 1.4 with max. resolution of 4096 x 2304 @60Hz. Please refer to www.intel.com for any updates\r\nOnly Intel 11th processors, support HDMI 2.0 with max. resolution of 4K@60Hz, others would only support HDM 1.4 with max. resolution of 4K@30Hz\r\nVGA resolution support depends on processors' or graphic cards' resolution

1 مسیر PCIe 4.0/3.0 x16 + 1 x PCIe 3.0 x16 (max. x4)\r\n1 مسیر PCIe 4.0/3.0 x16 slot\r\n2 مسیر PCIe 3.0 x1 slots

نقاط کنترل ولتاژ

Intel I225-V 2.5Gb Ethernet port, Intel Wi-Fi 6

Realtek ALC S1200A 7.1 Surround Sound High Definition Audio CODEC

سه عدد

شش عدد

WOL by PME, PXE

PCI-E 3.0 x4

1 مسیر PCIe 4.0/3.0 x16 + 1 x PCIe 3.0 x16 (max. x4)\r\n1 مسیر PCIe 4.0/3.0 x16 slot
