DDR4 5000(OC)/4800(OC)/4600(OC)/4400(OC)/4266(OC)/4000(OC)/3733(OC)/3600(OC)/3466(OC)/3333(OC)/3200(OC)/2933/2800/2666/2400/2133 مگاهرتز

8 فاز

Intel Socket LGA1200 for 11th Gen Intel Core Processors & 10th Gen Intel Core, Pentium Gold and Celeron Processors\r\nSupports Intel 14 nm CPU\r\nSupports Intel Turbo Boost Technology 2.0 and Intel Turbo Boost Max Technology 3.0\r\nIntel Turbo Boost Max Technology 3.0 support depends on the CPU types

یک عدد کومبو

16 مسیر

۰

۰

DDR4 5000(OC)/4800(OC)/4600(OC)/4400(OC)/4266(OC)/4000(OC)/3733(OC)/3600(OC)/3466(OC)/3333(OC)/3200(OC)/2933/2800/2666/2400/2133 MHz Non-ECC, Un-buffered Memory

۴ عدد USB 3.2 Gen 1 ports (4 x Type-A)\r\n۲ عدد USB 2.0 ports (2 x Type-A)\r\n۱ عدد D-Sub port\r\n۱ عدد HDMI port\r\n۱ عدد Intel I219-V 1Gb Ethernet\r\n۳ عدد Audio jacks\r\n۱ عدد PS/2 Keyboard/Mouse combo port

پنل پشتی:\r\n - ۴ عدد USB 3.2 Gen 1 ports (4 x Type-A)\r\n - ۲ عدد USB 2.0 ports (2 x Type-A)\r\nاتصالات داخلی:\r\n - ۱ عدد USB 3.2 Gen 1 header supports additional 2 USB 3.2 Gen 1 ports\r\n - ۲ عدد USB 2.0 headers support additional 4 USB 2.0 ports

۲ عدد M.2 slots (Key M)\r\n - Intel®11th Gen Processors\r\n - M.2_1 slot (Key M), type 2242/2260/2280\r\n - Only Intel 11th Gen processors support PCIe 4.0 x4 mode, this slot will be disabled for other CPUs\r\nIntel B560 Chipset\r\n - M.2_2 slot (Key M), type 2242/2260/2280 (supports PCIe 3.0 x4 & SATA modes)\r\n - ۶ عدد SATA 6Gb/s port\r\n - The M.2_2 shares bandwidth with SATA6G_2.When M.2_2 runs SATA mode, SATA6G_2 will be disabled

۱ عدد 4pin CPU Fan header\r\n۱ عدد 4pin Chassis Fan header\r\n۱ عدد 24pin Main Power connector\r\n۱ عدد 8pin+12V Power connector\r\n۱ عدد USB 3.2 Gen 1 header supports additional 2 USB 3.2 Gen 1 ports\r\n۲ عدد USB 2.0 headers support additional 4 USB 2.0 ports\r\n۱ عدد RGB header\r\n۱ عدد Clear CMOS header\r\n۱ عدد Front Panel Audio header (AAFP)\r\n۱ عدد COM Port header\r\n۱ عدد S/PDIF Out header\r\n۱ عدد Speaker header\r\n۱ عدد SPI TPM header (14-1pin)\r\n۱ عدد 10/1pin System Panel header\r\n\r\n\r\n

۱ عدد ASUS LANGuard

Realtek ALC897 7.1 Surround Sound High Definition Audio CODEC\r\n - Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking\r\n - Supports up to 24-Bit/192 kHz playback\r\nAudio Features\r\n - Audio Shielding\r\n - Premium Japanese audio capacitors\r\n - Dedicated audio PCB layers\r\nA chassis with an HD audio module in the front panel is required to support 7.1 Surround Sound audio output

Memory Channels:2DDR4 (Dual Channel)\r\nMax Memory Size:64GB\r\nDDR4 5000(OC)/4800(OC)/4600(OC)/4400(OC)/4266(OC)/4000(OC)/3733(OC)/3600(OC)/3466(OC)/3333(OC)/3200(OC)/2933/2800/2666/2400/2133 MHz Non-ECC, Un-buffered Memory\r\nDual Channel Memory Architecture\r\nSupports Intel Extreme Memory Profile (XMP)\r\n10th Gen Intel Core i7/i9 processors support 2933/2800/2666/2400/2133 natively, others will run at the maximum transfer rate of DDR4 2666MHz\r\n11th Gen Intel processors support 2933/2800/2666/2400/2133 natively\r\n Memory QVL (Qualified Vendors Lists)

64 گیگابایت

128Mb Flash ROM, UEFI AMI BIOS\r\n\r\n

۱ عدد D-Sub\r\n۱ عدد HDMI 1.4 / 2.0\r\nGraphics specifications may vary between CPU types\r\nOnly Intel 11th Gen processors support HDMI 2.0 with max. resolution of 4K@60Hz, others will only support HDMI 1.4 with max. resolution of 4K@30Hz

۱ مسیر PCIe 4.0/3.0 x16 slot\r\n۲ مسیر PCIe 3.0 x1 slots

Intel I219-V 1Gb Ethernet

Realtek ALC897 7.1 Surround Sound High Definition Audio CODEC

WOL by PME, PXE

۱ مسیر PCIe 4.0/3.0 x16 slot
