2666 مگاهرتز

دو عدد

7 فاز

Intel Socket 1151 9th / 8th Gen Intel Core, Pentium Gold and Celeron Processors\r\nSupports Intel 14 nm CPU\r\nSupports Intel Turbo Boost Technology 2.0\r\nThe Intel Turbo Boost Technology 2.0 support depends on the CPU types

دو مسیره

RAID 0

یک عدد کومبو

چهار عدد

یک عدد

24 مسیر

۰

۰

۱ عدد PS/2 keyboard/mouse combo port\r\n۱ عدد DVI-D\r\n۱ عدد D-Sub\r\n۱ عدد HDMI\r\n۱ عدد LAN (RJ45) port\r\n۴ عدد USB 3.1 Gen 1 (blue) up to 5Gbps\r\n۲ عدد USB 2.0\r\n۳ عدد Audio jack

۸ عدد USB 3.1 Gen 1 port(s) (4 at back panel, blue, 4 at mid-board)\r\n۶ عدد USB 2.0 port(s) (2 at back panel, black, 4 at mid-board)

Intel® B365 Chipset\r\n - ۱ عدد M.2 Socket 3, , with M Key, type 2242/2260/2280 storage devices support (SATA & PCIE 3.0 X2 mode)\r\n - ۱ عدد M.2 Socket 3, , with M key, type 2242/2260/2280/22110 storage devices support (PCIE 3.0 x 4 mode)\r\n - ۶ عدد SATA 6Gb/s port(s), gray\r\n - پشتیبانی از RAIDهای ۰، ۱، ۵ و ۱۰\r\nIntel Optane Memory Ready\r\nIntel CPU with Intel Rapid Storage Technology support (RAID 0 & RAID 1)

۲ عدد USB 3.1 Gen 1(up to 5Gbps) connector(s) support(s) additional 4 USB 3.1 Gen 1 port(s) (19-pin)\r\n۲ عدد USB 2.0 connector(s) support(s) additional 4 USB 2.0 port(s)\r\n۲ عدد Aura RGB Strip Header\r\n۱ عدد TPM header\r\n۱ عدد S/PDIF out header\r\n۱ عدد System panel(s) (Chassis intrusion header is inbuilt)\r\n۱ عدد COM port header\r\n۱ عدد Mono Out header

۱ عدد Gigabit LAN Controller\r\nASUS LAN Guard

Realtek ALC887 8-Channel High Definition Audio CODEC\r\n- Supports : Jack-detection, Front Panel Jack-retasking\r\nAudio Feature :\r\n- Audio Shielding: Ensures precision analog/digital separation and greatly reduced multi-lateral interference\r\n- Dedicated audio PCB layers: Separate layers for left and right channels to guard the quality of the sensitive audio signals\r\n- Premium Japanese audio capacitors: Provide warm, natural and immersive sound with exceptional clarity and fidelity\r\nپوشش فلزی روی چیپ\r\nلایه های PCB مجزا\r\nخازن های ژاپنی Premium

۴ عدد DIMM, Max. 64GB, DDR4 2666/2400/2133 MHz Non-ECC, Un-buffered Memory\r\nDual Channel Memory Architecture\r\nSupports Intel Extreme Memory Profile (XMP)\r\nMemory QVL (Qualified Vendors Lists)\r\nThe maximum memory frequency supported varies by processor\r\nDDR4 2666MHz and higher memory modules will run at max. 2666MHz on Intel 8th Gen. 6-core or higher processors

64 گیگابایت

۱ عدد Clear CMOS jumper

128 Mb Flash ROM, UEFI AMI BIOS, PnP, SM BIOS 3.1, ACPI 6.1, Multi-language BIOS, ASUS EZ Flash 3, CrashFree BIOS 3, F11 EZ Tuning Wizard, F6 Qfan Control, F3 My Favorites, Last Modified log, F9 Search, F12 PrintScreen, and ASUS DRAM SPD (Serial Presence Detect) memory information\r\n

Graphic\r\n - Integrated Graphics Processor- Intel UHD Graphics support\r\n - Multi-VGA output support : HDMI/DVI-D/D-Sub ports\r\n - Supports HDMI 1.4b with max. resolution 4096 x 2160 @ 24 Hz\r\n - Supports DVI-D with max. resolution 1920 x 1200 @ 60 Hz\r\n - Supports D-sub with max. resolution 1920 x 1200 @ 60 Hz\r\n - Supports Intel InTru 3D, Quick Sync Video, Clear Video HD Technology, Insider\r\n\r\nMulti-GPU Support\r\n - Supports AMD 2-Way CrossFireX Technology

Realtek RTL8111H

شش عدد

کانکتور برق اصلی 24 پبن ATX

WfM 2.0, DMI 3.0, WOL by PME, PXE

When the M.2_1 is operating in SATA mode, SATA_2 port 2 will be disabled.

PCI-E 3.0 x4

۱ مسیر PCIe 3.0/2.0 x16 (x16 mode)\r\n۱ مسیر PCIe 3.0/2.0 x16 (max at x4 mode)\r\n۴ مسیر PCIe 3.0/2.0 x1
