DDR4 5100(O.C)/4800(O.C.)/4600(O.C)/4400(O.C)/4266(O.C.)/4133(O.C.)/4000(O.C.)/3866(O.C.)/3733(O.C.)/3600(O.C.)/3466(O.C.)/3400(O.C.)/3200(O.C.)/3000(O.C.)/2933/2800/2666/2400/2133 مگاهرتز

دو عدد کابل SATA

12 فاز

AMD AM4 Socket for AMD Ryzen 5000 Series/ 4000 G-Series/ 3000 Series/ 3000 G-Series/ 2000 Series/ 2000 G-Series Desktop Processors

دو مسیره

RAID 0

یک عدد کومبو

یک عدد

24 مسیر

۰

۰

5100(O.C)/4800(O.C.)/4600(O.C)/4400(O.C)/4266(O.C.)/4133(O.C.)/4000(O.C.)/3866(O.C.)/3733(O.C.)/3600(O.C.)/3466(O.C.)/3400(O.C.)/3200(O.C.)/3000(O.C.)/2933/2800/2666/2400/2133

۱ عدد PS/2 keyboard/mouse combo port\r\n۱ عدد HDMI\r\n۱ عدد LAN (RJ45) port\r\n۲ عدد USB 2.0\r\n۳ عدد Audio jack\r\n۲ عدد USB 3.2 Gen 1 (up to 5Gbps) ports Type-A\r\n۴ عدد USB 3.2 Gen 2 (up to 10Gbps) ports (Type-A)\r\n

در استفاده از AMD Ryzen 5000 Series/ 3000 Series Desktop Processors\r\n - ۱ عدد M.2_1 socket 3, with M Key, Type 2242/2260/2280 (PCIE 4.0 x4 and SATA modes) storage devices support\r\nدر استفاده از AMD Ryzen 4000 G-Series / 3000 G-Series/ 2000 Series/ 2000 G-Series Desktop Processors\r\n - ۱ عدد M.2_1 socket 3, with M Key, Type 2242/2260/2280 (PCIE 3.0 x4 and SATA modes) storage devices support\r\nAMD X570 chipset\r\n - ۱ عدد M.2_2 socket 3, with M Key, Type 2242/2260/2280/22110(PCIE 4.0 x4 and SATA modes) storage devices support\r\n - ۶ عدد SATA 6Gb/s port\r\nSupport Raid 0, 1, 10

۲ عدد Aura RGB Strip Headers\r\n۱ عدد Addressable Gen 2 header\r\n۲ عدد USB 2.0 connector(s) support(s) additional 3 USB 2.0 port(s)\r\n1 x M.2 Socket 3 with M Key, type 2242/2260/2280 storage devices support (SATA mode & X4 PCIE mode)\r\n۲ عدد USB 3.2 Gen 1 (up to 5Gbps) connector support additional 4 USB ports\r\n۱ عدد SPI TPM header\r\n۱ عدد COM port connector\r\n۱ عدد S/PDIF out header\r\n۱ عدد Front panel audio connector\r\n۱ عدد System panel\r\n۱ عدد Clear CMOS jumper\r\n

ASUS LAN Guard\r\n

Realtek S1200A 8-Channel High Definition Audio CODEC \r\n- Supports : Front Panel Jack-retasking, up to 24-Bit/192kHz playback\r\n- Front panel audio connector (AAFP)\r\nAudio Feature :\r\n- Audio Shielding\r\n- Dedicated audio PCB layers\r\n- Premium Japanese-made audio capacitors\r\nChoose the chassis with HD audio module in front panel to support 8-channel audio output

AMD X570

۴ عدد DIMM, Max. 128GB, DDR4 5100(O.C)/4800(O.C.)/4600(O.C)/4400(O.C)/4266(O.C.)/4133(O.C.)/4000(O.C.)/3866(O.C.)/3733(O.C.)/3600(O.C.)/3466(O.C.)/3400(O.C.)/3200(O.C.)/3000(O.C.)/2933/2800/2666/2400/2133 MHz Un-buffered Memory\r\nDual Channel Memory Architecture\r\nECC Memory (ECC mode) support varies by CPU.\r\nMemory QVL (Qualified Vendors Lists)\r\nThe maximum memory capacity supported vary depending on the CPU you installed

۱ عدد Clear CMOS jumper

256 Mb Flash ROM, UEFI AMI BIOS, PnP, SM BIOS 3.2, ACPI 6.2, Multi-language BIOS, ASUS EZ Flash 3, CrashFree BIOS 3, F6 Qfan Control, F3 My Favorites, Last Modified log, F12 PrintScreen, F4 AURA ON/OFF, F9 Search and ASUS DRAM SPD (Serial Presence Detect) memory information

Integrated Graphics in AMD Ryzen 4000 G-Series/ 3000 G-Series/ 2000 G-Series Desktop Processors\r\nVGA output support : HDMI port\r\n- Supports HDMI 1.4b with max. resolution 4096 x 2160 @ 24 Hz

در استفاده از AMD Ryzen 5000 Series/ 3000 Series Desktop Processors\r\n - ۱ مسیر PCIe 4.0 x16 (x16 mode)\r\nدر استفاده از AMD Ryzen 4000 G-Series / 2000 Series Processors\r\n - ۱ مسیر PCIe 3.0 x16 (x16 mode)\r\nدر استفاده از AMD Ryzen 3000 G-Series / 2000 G-Series Processors\r\n - PCIe 3.0 x16 (x8 mode)\r\nAMD X570 chipset\r\n - ۱ عدد PCIe 4.0 x16 (max at x4 mode)\r\n - ۳ عدد PCIe 4.0 x1\r\n

نقاط کنترل ولتاژ

Realtek RTL8111H

Realtek S1200A

دو عدد

شش عدد

کانکتور برق اصلی 24 پبن ATX

5 عدد

WOL by PME, PXE

در استفاده از AMD Ryzen 5000 Series/ 3000 Series Desktop Processors\r\n - ۱ مسیر PCIe 4.0 x16 (x16 mode)\r\nدر استفاده از AMD Ryzen 4000 G-Series / 2000 Series Processors\r\n - ۱ مسیر PCIe 3.0 x16 (x16 mode)\r\nدر استفاده از AMD Ryzen 3000 G-Series / 2000 G-Series Processors\r\n - PCIe 3.0 x16 (x8 mode)\r\nAMD X570 chipset\r\n - ۱ عدد PCIe 4.0 x16 (max at x4 mode)\r\n - ۳ عدد PCIe 4.0 x1\r\nSupports AMD 2-Way CrossFireX Technology
