5133(OC)/5000(OC)/4800(OC)/4700(OC)/4600(OC)/4500(OC)/4400(OC)/4266(OC)/4133(OC)/4000(OC)/3866(OC)/3733(OC)/3600(OC)/3466(OC)/3400(OC)/3333(OC)/3200/3000/2933/2800/2666/2400/2133 مگاهرتز

12 فاز

Intel Socket LGA1200 for 11th Gen Intel Core processors & 10th Gen Intel Core, Pentium Gold and Celeron Processors\r\nSupports Intel 14 nm CPU\r\nSupports Intel Turbo Boost Technology 2.0 and Intel Turbo Boost Max Technology 3.0 \r\n

یک عدد کومبو

24 مسیر

۰

1

5133(OC)/5000(OC)/4800(OC)/4700(OC)/4600(OC)/4500(OC)/4400(OC)/4266(OC)/4133(OC)/4000(OC)/3866(OC)/3733(OC)/3600(OC)/3466(OC)/3400(OC)/3333(OC)/3200/3000/2933/2800/2666/2400/2133 MHz Non-ECC, Un-buffered Memory

۱ عدد USB 3.2 Gen 2x2 port (1 x USB Type-C®)\r\n۱ عدد USB 3.2 Gen 2 port (1 x Type-A)\r\n۲ عدد USB 3.2 Gen 1 ports (2 x Type-A)\r\n۲ عدد USB 2.0 ports (2 x Type-A)\r\n۱ عدد HDMI\r\n۱ عدد DisplayPort\r\n۱ عدد V-M.2 slot (Key E)\r\n۱ عدد Realtek 2.5Gb Ethernet port\r\n۵ عدد Audio jacks\r\n۱ عدد Optical S/PDIF out port\r\n۱ عدد PS/2 Keyboard/Mouse combo port

۳ عدد M.2 slots and 4 x SATA 6Gb/s port\r\nIntel 11th Gen Processors\r\n - Only Intel® 11th Gen processors support PCIe 4.0 x4 mode, this slot will be disabled for other CPUs\r\nIntel Z590 Chipset\r\nM.2_3 slot (Key M), type 2242/2260/2280/22110 (supports PCIe 3.0 x4 & SATA modes)\r\n۴ عدد SATA 6Gb/s ports\r\n

۱ عدد 4-pin CPU Fan header\r\n۱ عدد 4-pin AIO Pump header\r\n۳ عدد 4-pin Chassis Fan headers\r\n۱ عدد 24-pin Main Power connector\r\n۱ عدد 8-pin +12V Power connector\r\n۱ عدد 4-pin +12V Power connector\r\n۳ عدد M.2 slots (Key M)\r\n۴ عدد SATA 6Gb/s ports\r\n۱ عدد USB 3.2 Gen 1 connector (supports USB Type-C)\r\n۲ عدد USB 3.2 Gen 1 headers support additional 4 USB 3.2 Gen 1 ports\r\n۲ عدد USB 2.0 headers support additional 4 USB 2.0 ports\r\n۲ عدد AURA Addressable Gen 2 headers\r\n۲ عدد AURA RGB header\r\n۱ عدد Clear CMOS header\r\n۱ عدد COM Port header\r\n۱ عدد Front Panel Audio header (AAFP)\r\n۱ عدد SPI TPM header (14-1pin)\r\n۱ عدد 20-5pin System Panel header\r\n۱ عدد Thunderbolt™ header\r\n\r\n

پشتیبانی از LANGuard

Realtek ALC887 8-Channel High Definition Audio CODEC\r\n- Supports : Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking\r\n- Supports up to 24-Bit/192 kHz playback\r\nAudio Feature :\r\n- Audio Shielding\r\n- Rear optical S/PDIF out port\r\n- Premium Japanese audio capacitors\r\n- Dedicated audio PCB layers

۴ عدد DIMM, Max. 128GB, 5133(OC)/5000(OC)/4800(OC)/4700(OC)/4600(OC)/4500(OC)/4400(OC)/4266(OC)/4133(OC)/4000(OC)/3866(OC)/3733(OC)/3600(OC)/3466(OC)/3400(OC)/3333(OC)/3200/3000/2933/2800/2666/2400/2133 MHz Non-ECC, Un-buffered Memory\r\nDual Channel Memory Architecture\r\nSupports Intel Extreme Memory Profile (XMP)\r\n

192 (128+64) Mb Flash ROM, UEFI AMI BIOS\r\n

۱ عدد DisplayPort 1.4\r\n۱ عدد HDMITM 1.4 / 2.0

۱ مسیر PCIe 4.0/3.0 x16\r\n - Intel 11th Gen processors support PCIe 4.0 x16 or x8/x8 or x8/x4/x4 modes\r\n - Intel 10th Gen processors support PCIe 3.0 x16 or x8/x8 or x8/x4/x4 modes\r\n۱ مسیر PCIe 3.0 x16 (supports x4 mode)\r\n۲ مسیر PCIe 3.0 x1\r\n

نقاط کنترل ولتاژ

Realtek 2.5Gb Ethernet

Realtek ALC897 7.1 Surround Sound High Definition Audio CODEC

سه عدد

کانکتور برق اصلی 24 پبن ATX

5 عدد

WOL by PME, PXE

PCI-E 3.0 x4

۱ مسیر PCIe 4.0/3.0 x16\r\n - Intel 11th Gen processors support PCIe 4.0 x16 or x8/x8 or x8/x4/x4 modes\r\n - Intel 10th Gen processors support PCIe 3.0 x16 or x8/x8 or x8/x4/x4 modes\r\n۱ مسیر PCIe 3.0 x16 (supports x4 mode)\r\n۲ مسیر PCIe 3.0 x1

Intel LGA 1200

دو عدد
