2933/2800/2666/2400/2133 مگاهرتز

8 فاز

Intel Socket LGA1200 for 11th Gen Intel Core Processors & 10th Gen Intel Core, Pentium Gold and Celeron Processors\r\nSupports Intel 14 nm CPU\r\nSupports Intel Turbo Boost Technology 2.0 and Intel Turbo Boost Max Technology 3.0\r\nIntel Turbo Boost Max Technology 3.0 support depends on the CPU types

یک عدد برای کیبورد

16 مسیر

۰

۰

۲ عدد USB 3.2 Gen 1 ports (2 x Type-A)\r\n۲ عدد USB 2.0 ports (2 x Type-A)\r\n۱ عدد DisplayPort\r\n۱ عدد D-Sub port\r\n۱ عدد DVI-D port\r\n۱ عدد HDMI port\r\n۱ عدد COM port\r\n۱ عدد Intel I219-V 1Gb Ethernet port\r\n۱ عدد PS/2 keyboard (purple) port\r\n۱ عدد PS/2 mouse (green) port\r\n۳ عدد Audio jacks

پنل پشتی\r\n - ۲ عدد USB 3.2 Gen 1 ports (2 x Type-A)\r\n - ۴ عدد USB 2.0 ports (2 x Type-A)\r\nاتصالات داخلی\r\n - ۱ عدد USB 3.2 Gen 1 header supports additional 2 USB 3.2 Gen 1 ports\r\n - ۲ عدد USB 2.0 headers support additional 4 USB 2.0 ports

پشتیبانی از یک عدد M.2 slot and 4 x SATA 6Gb/s ports\r\nIntel H510 Chipset\r\nM.2 slot (Key M), type 2242/2260/2280 (supports PCIe 3.0 x4 & SATA modes)\r\n۴ عدد SATA 6Gb/s ports\r\nWhen a device in SATA mode is installed on the M.2 socket, SATA6G_2 port cannot be used

۱ عدد USB 3.2 Gen 1 header supports additional 2 USB 3.2 Gen 1 ports\r\n۲ عدد USB 2.0 headers support additional 4 USB 2.0 ports\r\n۱ عدد Clear CMOS header\r\n۱ عدد Chassis Intrude header\r\n۱ عدد COM Port header\r\n۱ عدد Front Panel Audio header (AAFP)\r\n۱ عدد COM debug header\r\n۱ عدد LPT header\r\n۱ عدد SMBUS header\r\n۱ عدد Speaker header\r\n۱ عدد SPI TPM header (14-1pin)\r\n۱ عدد 10/1pin System Panel header\r\n۱ عدد 4pin CPU Fan header\r\n۱ عدد 4pin Chassis Fan header\r\n

ASUS LANGuard

Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking\r\nSupports up to 24-Bit/192 kHz playback\r\nA chassis with an HD audio module in the front panel is required to support 7.1 Surround Sound audio output

3 عدد

Memory Channels:2DDR4 (Dual Channel)\r\nMax Memory Size:64GB\r\nDual Channel Memory Architecture\r\nSupports Intel Extreme Memory Profile (XMP)\r\n10th Gen Intel i7/i9 processors support 2933/2800/2666/2400/2133 natively, others will run at the maximum transfer rate of DDR4 2666MHz\r\n11th Gen Intel processors support 2933/2800/2666/2400/2133 natively\r\nMemory QVL (Qualified Vendors Lists)

128Mb Flash ROM, UEFI AMI BIOS\r\n\r\n

۱ عدد DisplayPort 1.4\r\n۱ عدد D-Sub\r\n۱ عدد DVI-D\r\n۱ عدد HDMI 2.0 \r\nGraphics specifications may vary between CPU types.\r\nIntel 11th & 10th processors support DisplayPort 1.4 with max. resolution of 4096 x 2304 @60Hz\r\nOnly Intel 11th processors support HDMI 2.0 with max. resolution of 4K@60Hz, others will only support HDMI 1.4 with max. resolution of 4K@30Hz\r\nSupports up to 2 displays simultaneously

۱ مسیر PCIe 4.0/3.0 x16 slot\r\n۲ مسیر PCIe 3.0 x1 slots\r\n۱ مسیر PCI slot

microATX

Intel I219-V 1Gb Ethernet

Realtek ALC897 7.1 Surround Sound High Definition Audio CODEC

چهار عدد

کانکتور برق اصلی 24 پبن ATX

4 عدد

WOL by PME, PXE

PCI-E 3.0 x4

۱ مسیر PCIe 4.0/3.0 x16 slot

Intel LGA 1200
