DDR4 2666/2400/2133 مگاهرتز

دو عدد

6 فاز

Intel Socket 1151 9th / 8th Gen Intel® Core, Pentium Gold and Celeron Processors\r\nSupports Intel 14 nm CPU\r\nSupports Intel Turbo Boost Technology 2.0 \r\nThe Intel Turbo Boost Technology 2.0 support depends on the CPU types\r\n

دو کاناله

۰

۰

Intel B360 Chipset :\r\n - ۲ عدد USB 3.1 Gen 2 up to 10Gbps port(s) (2 at back panel, teal blue, Type-A)\r\n - ۴ عدد USB 3.1 Gen 1 up to 5Gbps port(s) (2 at back panel, blue, Type-A, 2 at mid-board)\r\n - ۶ عدد USB 2.0 port(s) (4 at back panel, , 2 at mid-board)

Intel B360 Chipset\r\n - ۱ عدد M.2 Socket 3, with M Key, type 2242/2260/2280 storage devices support (SATA & PCIE 3.0 X2 mode)\r\n - ۱ عدد M.2 Socket 3, with M key, type 2242/2260/2280 storage devices support (PCIE 3.0 x 4 mode)\r\n - ۱ عدد SATA 6Gb/s port(s), gray

۱ عدد USB 3.2 Gen 1(up to 5Gbps) connector(s) support(s) additional 2 USB 3.2 Gen 1 port(s) (19-pin)\r\n۱ عدد USB 2.0 connector(s) support(s) additional 2 USB 2.0 port(s)\r\n۱ عدد S/PDIF out header\r\n۱ عدد COM port header

۱ عدد Gigabit LAN Controller

Realtek ALC887 8-Channel High Definition Audio CODEC\r\n- Supports : Jack-detection, Front Panel Jack-retasking\r\nAudio Feature :\r\n- LED-illuminated design - Brighten up your build with the gorgeous illuminated audio trace path\r\n- Dedicated audio PCB layers: Separate layers for left and right channels to guard the quality of the sensitive audio signals\r\n- Premium Japanese audio capacitors: Provide warm, natural and immersive sound with exceptional clarity and fidelity\r\nChoose the chassis with HD audio module in front panel to support 8-channel audio output\r\nپشتیبانی از jack-detection و front panel jack-retasking

3 عدد

Intel B360

چهار عدد DIMM, Max. 64GB, DDR4 2666/2400/2133 MHz Non-ECC, Un-buffered Memory\r\nDual Channel Memory Architecture\r\nSupports Intel Extreme Memory Profile (XMP)\r\nRefer to www.asus.com for the Memory QVL (Qualified Vendors Lists)\r\nThe maximum memory frequency supported varies by processor\r\nDDR4 2666MHz and higher memory modules will run at max. 2666MHz on Intel 8th Gen. 6-core or higher processors

۱ عدد Clear CMOS jumper\r\n۱ عدد System panel

128 Mb Flash ROM, UEFI AMI BIOS, PnP, SM BIOS 3.1, ACPI 6.1, Multi-language BIOS, ASUS EZ Flash 3, CrashFree BIOS 3, F11 EZ Tuning Wizard, F6 Qfan Control, F3 My Favorites, Last Modified log, F9 Search, F12 PrintScreen, and ASUS DRAM SPD (Serial Presence Detect) memory information

Integrated Graphics Processor- Intel® HD Graphics support\r\nMulti-VGA output support : HDMI/DVI-D/D-Sub ports\r\n- Supports HDMI 1.4b with max. resolution 4096 x 2160 @ 24 Hz / 2560 x 1600 @ 60 Hz\r\n- Supports DVI-D with max. resolution 1920 x 1200 @ 60 Hz\r\n- Supports D-sub with max. resolution 1920 x 1200 @ 60 Hz\r\nMaximum shared memory of 1024 MB (for iGPU exclusively)\r\nSupports Intel HD Graphics, InTru 3D, Quick Sync Video, Clear Video HD Technology, Insider\r\nSupports up to 3 displays simultaneously

ATX

نقاط کنترل ولتاژ

Realtek ALC887

8 کانال

کانکتور برق اصلی 24 پبن ATX

WOL by PME, PXE

The PCIe x1_1, PCIe x1_2 slots share bandwidth with PCIe x16_2. The PCIe x16_2 slot runs at x2 mode as default. Please check BIOS for more configuration\r\nWhen a device in SATA mode is installed on the M.2_1 socket, SATA_2 port cannot be used\r\nOnly the M.2_2 socket can support Intel Optane memory

PCI-E 3.0 x4

۱ مسیر PCIe 3.0/2.0 x16 (x16 mode)\r\n۱ مسیر PCIe 3.0/2.0 x16 (max at x4 mode)\r\n۲ مسیر PCIe 3.0/2.0 x1\r\n۲ مسیر PCI

DDR4

Intel LGA 1151

یک عدد
