DDR4 3200(OC)/2933/2800/2666/2400/2133 مگاهرتز

8 فاز

Intel Socket LGA1200 for 11th Gen Intel Core Processors & 10th Gen Intel Core, Pentium Gold and Celeron Processors\r\nSupports Intel 14 nm CPU\r\nSupports Intel Turbo Boost Technology 2.0 and Intel Turbo Boost Max Technology 3.0\r\nIntel Turbo Boost Max Technology 3.0 support depends on the CPU types

یک عدد برای ماوس

دو عدد

16 مسیر

۰

۰

DDR4 3200(OC)/2933/2800/2666/2400/2133 MHz Non-ECC, Un-buffered Memory

۲ عدد USB 3.2 Gen 1 ports (2 x Type-A)\r\n۲ عدد USB 2.0 ports (2 x Type-A)\r\n۱ عدد DisplayPort\r\n۱ عدد D-Sub port\r\n۱ عدد HDMI port\r\n۱ عدد Intel I219-V 1Gb Ethernet port\r\n۳ عدد Audio jacks\r\n۱ عدد PS/2 Keyboard (purple) port\r\n۱ عدد PS/2 Mouse (green) port

پنل پشتی:\r\n - ۲ عدد USB 3.2 Gen 1 ports (2 x Type-A)\r\n - ۲ عدد USB 2.0 ports (2 x Type-A)\r\nاتصالات داخلی:\r\n - ۱ عدد USB 3.2 Gen 1 header supports additional 2 USB 3.2 Gen 1 ports\r\n - ۲ عدد USB 2.0 headers support additional 4 USB 2.0 ports

۱ عدد M.2 slot and 4 x SATA 6Gb/s ports\r\nIntel H510 Chipset\r\nM.2 slot (Key M), type 2242/2260/2280 (supports PCIe 3.0 x4 & SATA modes)\r\n۴ عدد SATA 6Gb/s ports\r\nThe M.2 slot shares bandwidth with SATA6G_2. When a device in SATA mode is installed on the M.2 slot, SATA6G_2 port cannot be used

۱ عدد 4pin CPU Fan header\r\n۱ عدد 4pin Chassis Fan header\r\n۱ عدد 24pin Main Power connector\r\n۱ عدد 8pin +12V Power connector\r\n۱ عدد M.2 slot (Key M)\r\n۴ عدد SATA 6Gb/s port\r\n۱ عدد USB 3.2 Gen 1 header supports additional 2 USB 3.2 Gen 1 port\r\n۱ عدد USB 2.0 header supports additional 2 USB 2.0 port\r\n۱ عدد RGB header\r\n۱ عدد Clear CMOS header\r\n۱ عدد COM Port header\r\n۱ عدد Front Panel Audio header (AAFP)\r\n۱ عدد S/PDIF Out header\r\n۱ عدد Speaker header\r\n۱ عدد 10-1 pin System Panel header

ASUS LANGuard\r\n

ALC897/887\r\nRealtek ALC897/887 7.1 Surround Sound High Definition Audio CODEC\r\n- Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking\r\n- Supports up to 24-Bit/192 kHz playback\r\nAudio Features\r\n- Audio Shielding\r\n- Premium Japanese audio capacitors\r\n- Dedicated audio PCB layers\r\nA chassis with an HD audio module in the front panel is required to support 7.1 Surround Sound audio output

Memory Channels:2DDR4 (Dual Channel)\r\nMax Memory Size:64GB\r\nDDR4 3200(OC)/2933/2800/2666/2400/2133 MHz Non-ECC, Un-buffered Memory\r\nDual Channel Memory Architecture\r\nSupports Intel Extreme Memory Profile (XMP)\r\n10th Gen Intel Core i7/i9 processors support 2933/2800/2666/2400/2133 natively, others will run at the maximum transfer rate of DDR4 2666MHz\r\n11th Gen Intel processors support 2933/2800/2666/2400/2133 natively\r\n

128Mb Flash ROM, UEFI AMI BIOS\r\n\r\n

۱ عدد D-Sub\r\n۱ عدد HDMI 1.4 / 2.0\r\n۱ عدد DisplayPort 1.4\r\n

پردازنده‌های نسل ۱۰ و ۱۱ اینتل:\r\n۱ مسیر PCIe 4.0/3.0 x16 slot\r\n- Intel 11th Gen processors support PCIe 4.0 x16\r\n- Intel 10th Gen processors support PCIe 3.0 x16\r\nچیپست H510 اینتل:\r\n۱ مسیر PCIe 3.0 x1 slots

نقاط کنترل ولتاژ

Intel I219-V 1Gb Ethernet port

Realtek ALC897/887 7.1 Surround Sound High Definition Audio CODEC

یک عدد

کانکتور برق اصلی 24 پبن ATX

WOL by PME, PXE

PCI-E 3.0 x4

۱ مسیر PCIe 4.0/3.0 x16 slot

Intel LGA 1200
