پشتیبانی از نسل 11 و 10 پردازنده‌های Intel Core و Pentium Gold and Celeron\r\nپشتیبانی از Intel 14 nm CPU\r\nپشتیبانی از Intel Turbo Boost Technology 2.0 and Intel Turbo Boost Max Technology 3.0

24 مسیر

1 عدد

5133(OC)/5000(OC)/4800(OC)/4700(OC)/4600(OC)/4500(OC)/4400(OC)/4266(OC)/4133(OC)/4000(OC)/3866(OC)/3733(OC)/3600(OC)/3466(OC)/3400(OC)/3333(OC)/3200

2 عدد USB 3.2 Gen 2x2 port (1 x USB Type-C)\r\n3 عدد USB 3.2 Gen 2 ports (3 x Type-A)\r\n4 عدد USB 2.0 ports (4 x Type-A)\r\n1 عدد DisplayPort\r\n1 عدد HDMI port\r\n1 عدد Intel I225-V 2.5Gb Ethernet port\r\n5 عدد Audio jacks\r\n1 عدد Optical S/PDIF out port

پنل پشتی:\r\n - 1 عدد USB 3.2 Gen 2x2 port (1 x USB Type-C)\r\n - 1 عدد USB 3.2 Gen 2 port (1 x Type-A)\r\n - 2 عدد USB 3.2 Gen 1 ports (2 x Type-A)\r\n- 2 عدد USB 2.0 ports (2 x Type-A)\r\n

Total supports 3 x M.2 slots and 4 x SATA 6Gb/s ports Intel® 11th Gen Processors M.2_1 slot (Key M), type 2242/2260/2280/22110

1 عدد 4-pin CPU Fan header\r\n1 عدد 4-pin AIO Pump header\r\n3 عدد 4-pin Chassis Fan headers\r\n3 عدد M.2 slots (Key M)\r\n4 عدد SATA 6Gb/s port\r\n2 عدد AURA Addressable Gen 2 headers\r\n2 عدد AURA RGB headers\r\n1 عدد Clear CMOS header\r\n1 عدد COM Port header\r\n1 عدد Front Panel Audio header (AAFP)\r\n1 عدد SPI TPM header (14-1pin)\r\n1 عدد 20-5pin System Panel header\r\n1 عدد Thunderbolt header

4 عدد DIMM, Max. 128GB, DDR4\r\n5133(OC)/5000(OC)/4800(OC)/4700(OC)/4600(OC)/4500(OC)/4400(OC)/4266(OC)/4133(OC)/4000(OC)/3866(OC)/3733(OC)/3600(OC)/3466(OC)/3400(OC)/3333(OC)/3200/3000/2933/2800/2666/2400/2133 MHz\r\nNon-ECC, Un-buffered Memory\r\nDual Channel Memory Architecture\r\nSupports Intel Extreme Memory Profile (XMP)\r\nOptiMem II

Realtek ALC897 7.1 Surround Sound High Definition Audio CODEC\r\n- Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking\r\n- Supports up to 24-Bit/192 kHz playback"\r\nAudio Features\r\n- Audio Shielding\r\n- Rear optical S/PDIF out port\r\n- Premium Japanese audio capacitors\r\n- Dedicated audio PCB layers

5 عدد

256Mb Flash ROM, UEFI AMI BIOS\r\n

1 عدد DisplayPort 1.4\r\n1 عدد HDMI 2.0

3 مسیر PCIe 4.0/3.0 x16 slots\r\n1 مسیر PCIe 3.0 x4 slot\r\n

Thunderbolt

Realtek 2.5Gb Ethernet

Realtek ALC897 7.1 Surround Sound High Definition Audio CODEC

7.1 کاناله کانال

سه عدد

شش عدد

کانکتور برق 4 پین ATX

4 عدد

WOL by PME, PXE\r\n

V-M.2 slot only (Key E, CNVi & PCIe)\r\nWi-Fi module and vertical M.2 Key E bracket set are purchased separately.

Key M

1 مسیر PCIe 4.0/3.0 x16 slot برای پردازنده‌های نسل 10 و 11 اینتل

Intel LGA 1200
