DDR4 5333(OC)/5133(OC)/5000(OC)/4800(OC)/4700(OC)/4600(OC)/4500(OC)/4400(OC)/4266(OC)/4133(OC)/4000(OC)/3866(OC)/3733(OC)/3600(OC)/3466(OC)/3400(OC)/3333(OC)/3200/3000/2933/2800/2666/2400/2133 مگاهرتز

17 فاز

24 مسیر

DDR4 5333(OC)/5133(OC)/5000(OC)/4800(OC)/4700(OC)/4600(OC)/4500(OC)/4400(OC)/4266(OC)/4133(OC)/4000(OC)/3866(OC)/3733(OC)/3600(OC)/3466(OC)/3400(OC)/3333(OC)/3200/3000/2933/2800/2666/2400/2133 MHz Non-ECC, Un-buffered Memory

پنل پشتی:\r\n - ۱ عدد USB 3.2 Gen 2x2 port (1 x USB Type-C)\r\n - ۴ عدد USB 3.2 Gen 2 ports (3 x Type-A, 1 x Type-C)\r\n - ۴ عدد USB 2.0 ports (4 x Type-A)\r\nاتصالات داخلی:\r\n - ۱ عدد USB 3.2 Gen 1 connector (suppports USB Type-C)\r\n - ۱ عدد USB 3.2 Gen 1 header supports additional 2 USB 3.2 Gen 1 ports\r\n - ۲ عدد USB 2.0 headers support additional 4 USB 2.0 ports

Total supports 3 x M.2 slots and 6 x SATA 6Gb/s ports\r\nIntel 11th Gen Processors\r\nM.2_1 slot (Key M), type 2242/2260/2280/22110\r\n- Only Intel 11th Core processors support PCIe 4.0 x4 mode, this slot will be disabled for other CPUs\r\nIntel Z590 Chipset\r\nM.2_2 slot (Key M), type 2242/2260/2280/22110 (supports PCIe 3.0 x4 & SATA modes)\r\nM.2_3 slot (Key M), type 2242/2260/22110 (supports PCIe 3.0 x4 & SATA modes)\r\n۶ عدد SATA 6Gb/s ports\r\nRaid function for PCIe mode SSD in Intel Rapid Storage Technology is available with either 1. Intel SSDs installed in both CPU-attached and PCH-attached slots, or 2. any other 3rd party SSDs installed in PCH-attached slots.\r\nTo enable Intel Optane Memory (Hybrid Storage device), it must be installed in PCH-attached slots with Intel® Rapid Storage Technology\r\nM.2_2 shares bandwidth with SATA6G_2. When M.2_2 runs SATA mode, SATA6G_2 will be disabled\r\nM.2_3 shares bandwidth with SATA6G_6. When M.2_6 runs SATA mode, SATA6G_6 will be disabled

۱ عدد USB 3.2 Gen 1 connector (supports USB Type-C)\r\n۱ عدد USB 3.2 Gen 1 headers supports additional 2 USB 3.2 Gen 1 ports\r\n۲ عدد USB 2.0 headers support additional 4 USB 2.0 ports\r\n۳ عدد AURA Addressable Gen 2 headers\r\n۱ عدد AURA RGB headers\r\n۱ عدد Clear CMOS header\r\n۱ عدد COM Port header\r\n۱ عدد SPI TPM header (14-1pin)\r\n۱ عدد 20/3pin System Panel header with Chassis intrude function\r\n۱ عدد Thermal Sensor header\r\n۱ عدد Thunderbolt header

Impedance sense for front and rear headphone outputs\r\n - Internal audio Amplifier to enhance the highest quality sound for headphone and speakers\r\n - Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking\r\n - High quality 120 dB SNR stereo playback output and 113 dB SNR recording input (Line-in)\r\n - Supports up to 32-Bit/192 kHz playback\r\nAudio Features:\r\n - Power pre-regulator reduces power input noise to ensure consistent performance\r\n - Rear optical S/PDIF out port\r\n - Premium Japanese audio capacitors\r\n - Audio Shielding\r\n - Dedicated audio PCB layers\r\n - Audio cover\r\n - Unique de-pop circuit\r\nDue to limitations in HDA bandwidth, 32-Bit/192kHz is not supported for 8-Channel audio

5 عدد

۱ عدد Power button\r\n۱ عدد CPU Over Voltage jumper

256Mb Flash ROM, UEFI AMI BIOS\r\n

۱ عدد DisplayPort 1.4\r\n۱ عدد HDMI 2.0

۳ مسیر PCIe 4.0/3.0 x16 slots\r\n۱ مسیر PCIe 3.0 x4 slot\r\n

نقاط کنترل ولتاژ

Intel I225-V 2.5Gb Ethernet port

کانکتور برق اصلی 24 پبن ATX

WOL by PME, PXE

PCI-E 3.0 x4

۳ مسیر PCIe 4.0/3.0 x16 slots
