DDR4 3200(OC)/2933/2800/2666/2400/2133 مگاهرتز

8 فاز

Intel Socket LGA1200 for 11th Gen Intel Core Processors & 10th Gen Intel Core, PentiumGold and Celeron Processors\r\nSupports Intel® 14 nm CPU\r\nSupports Intel® Turbo Boost Technology 2.0 and Intel® Turbo Boost Max Technology 3.0\r\nIntel® Turbo Boost Max Technology 3.0 support depends on the CPU types

یک عدد برای ماوس

دو عدد

چهار عدد

16 مسیر

۰

۰

DDR4 3200(OC)/2933/2800/2666/2400/2133 MHz Non-ECC, Un-buffered Memory

۱ عدد PS/2 keyboard/mouse combo port\r\n۱ عدد DVI-D\r\n۱ عدد D-Sub (VGA)\r\n۱ عدد HDMI\r\n۱ عدد LAN (RJ45) port\r\n۲ عدد USB 3.2 Gen 2 (teal blue) (2 x Type-A)\r\n۴ عدد USB 3.2 Gen 1 (blue) Type-A\r\n۳ عدد Audio jack\r\n۱ عدد ASUS Wi-Fi Module

پنل پشتی\r\n - ۲ عدد USB 3.2 Gen 1 ports (2 x Type-A)\r\n - ۲ عدد USB 2.0 ports (2 x Type-A)\r\n\r\nاتصالات داخلی\r\n - ۱ عدد USB 3.2 Gen 1 header supports additional 2 USB 3.2 Gen 1 ports\r\n - ۲ عدد USB 2.0 headers support additional 4 USB 2.0 ports

۱ عدد M.2 slot and 4 x SATA 6Gb/s ports\r\nM.2 slot (Key M), type 2242/2260/2280 (supports PCIe 3.0 x4 & SATA modes)\r\n۴ عدد SATA 6Gb/s ports\r\nThe M.2 slot shares bandwidth with SATA6G_2. When a device in SATA mode is installed on the M.2 slot, SATA6G_2 port cannot be used

۲ عدد USB 3.2 Gen 1 header supports additional 2 USB 3.2 Gen 1 ports\r\n۱ عدد USB 2.0 headers support additional 4 USB 2.0 ports\r\n۱ عدد RGB header\r\n۱ عدد Clear CMOS header\r\n۱ عدد COM Port header\r\n۱ عدد Front Panel Audio header (AAFP)\r\n۱ عدد S/PDIF Out header\r\n۱ عدد Speaker header\r\n۱ عدد SPI TPM header (14-1pin)\r\n۱ عدد 10/1pin System Panel header\r\n۱ عدد 4pin CPU Fan header\r\n۱ عدد 4pin Chassis Fan header

Realtek ALC897/887 7.1 Surround Sound High Definition Audio CODEC\r\n- Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking\r\n- Supports up to 24-Bit/192 kHz playback\r\nAudio Features\r\n- Audio Shielding\r\n- Premium Japanese audio capacitors\r\n- Dedicated audio PCB layers\r\nA chassis with an HD audio module in the front panel is required to support 7.1 Surround Sound audio output

3 عدد

Intel Z97

Memory Channels:2DDR4 (Dual Channel)\r\nMax Memory Size:64GB\r\nDDR4 3200(OC)/2933/2800/2666/2400/2133 MHz Non-ECC, Un-buffered Memory\r\nDual Channel Memory Architecture\r\nSupports Intel® Extreme Memory Profile (XMP)\r\n10th Gen Intel® Core™ i7/i9 processors support 2933/2800/2666/2400/2133 natively, others will run at the maximum transfer rate of DDR4 2666MHz\r\n11th Gen Intel® processors support 2933/2800/2666/2400/2133 natively\r\nMemory QVL (Qualified Vendors Lists)

64 گیگابایت

۱ عدد Clear CMOS jumper

128Mb Flash ROM, UEFI AMI BIOS\r\n

۱ عدد DisplayPort 1.4\r\n۱ عدد D-Sub\r\n۱ عدد HDMI 2.0\r\nGraphics specifications may vary between CPU types.\r\nIntel 11th & 10th Gen processors support DisplayPort 1.4 with max. resolution of 4096 x 2304 @60Hz. Please refer to www.intel.com for any update\r\nOnly Intel 11th Gen processors support HDMI 2.0 with max. resolution of 4K@60Hz, others will only support HDMI 1.4 with max. resolution of 4K@30Hz. Please refer to www.intel.com for any updates\r\nExpansion Slots Intel 11th & 10th Gen Processors

۱ مسیر PCIe 4.0/3.0 x16 slot\r\n۲ مسیر PCIe 3.0 x1 slots

نقاط کنترل ولتاژ

Intel I219-V 1Gb Ethernet

Realtek ALC897/887 7.1 Surround Sound High Definition Audio CODEC

کانکتور برق اصلی 24 پبن ATX

WOL by PME, PXE

PCI-E 3.0 x4

۱ مسیر PCIe 4.0/3.0 x16 slot
