5100(O.C.) / 5000(O.C.) / 4866(O.C.) / 4600(O.C.) / 4400(O.C.) / 4000(O.C.) / 3600(O.C.) / 3333(O.C.) /3200/2933/2667/2400/2133 // 5200(O.C.) / 5000(O.C.) / 4866(O.C.) / 4600(O.C.) / 4400(O.C.) / 4000(O.C.) / 3600(O.C.) / 3333(O.C.) /3200/2933/2667/2400/2133 // 5400(O.C.) / 5200(O.C.) / 5000(O.C.) / 4866(O.C.) / 4600(O.C.) / 4400(O.C.) / 4000(O.C.) / 3600(O.C.) / 3333(O.C.) /3200/2933/2667/2400/2133 مگاهرتز

سه عدد

16 فاز

AMD Socket AM4, support for : AMD Ryzen 5000 Series / 3rd Generation AMD Ryzen processors / 3rd Gen AMD Ryzen with Radeon Graphics processors

پنج عدد

24 مسیر

AMD Ryzen 5000 series Processors:\r\nSupport for DDR4 5100(O.C.) / 5000(O.C.) / 4866(O.C.) / 4600(O.C.) / 4400(O.C.) / 4000(O.C.) / 3600(O.C.) / 3333(O.C.)\r\n3rd Gen AMD Ryzen Processors:\r\nSupport for DDR4 5200(O.C.) / 5000(O.C.) / 4866(O.C.) / 4600(O.C.) / 4400(O.C.) / 4000(O.C.) / 3600(O.C.) / 3333(O.C.)\r\n3rd Gen AMD Ryzen with Radeon Graphics processors:\r\nSupport for DDR4 5400(O.C.) / 5200(O.C.) / 5000(O.C.) / 4866(O.C.) / 4600(O.C.) / 4400(O.C.) / 4000(O.C.) / 3600(O.C.) / 3333(O.C.)

1 عدد HDMI port\r\n2 عدد SMA antenna connectors (1T1R)\r\n6 عدد USB 2.0/1.1 ports\r\n5 عدد USB 3.2 Gen 2 Type-A ports (red)\r\n1 عدد USB Type-C port, with USB 3.2 Gen 2 support\r\n1 عدد RJ-45 port\r\n1 عدد optical S/PDIF Out connector\r\n5 عدد audio jacks

CPU:\r\nUSB 3.2 Gen 2 Type-A ports (red) on the back panel\r\nChipset:\r\n1 عدد USB Type-C port on the back panel, with USB 3.2 Gen 2 support\r\n1 عدد USB 3.2 Gen 2 Type-A port (red) on the back panel\r\n2 عدد USB 3.2 Gen 1 ports available through the internal USB header\r\n2 عدد USB 2.0/1.1 ports on the back panel\r\nChipset+2 USB 2.0 Hubs:\r\n8 عدد USB 2.0/1.1 ports (4 ports on the back panel, 4 ports available through the internal USB headers)

1 عدد M.2 connector (M2A_CPU), integrated in the CPU, supporting Socket 3, M key, type 2242/2280/22110 SSDs:\r\n3rd Generation AMD Ryzen™ processors support SATA and PCIe 4.0 x4/x2 SSDs\r\nNew Generation AMD Ryzen with Radeon Graphics processors support SATA and PCIe 3.0 x4/x2 SSDs\r\n2 عدد M.2 connectors (M2B_CPU/M2C_CPU), integrated in the CPU, supporting Socket 3, M key, type 2242/2280/22110 SSDs:\r\n3rd Generation AMD Ryzen processors support PCIe 4.0 x4/x2 SSDs\r\nNew Generation AMD Ryzen with Radeon Graphics processors support PCIe 3.0 x4/x2 SSDs\r\n6 عدد SATA 6Gb/s connectors, integrated in the Chipset:\r\nSupport for RAID 0, RAID 1, and RAID 10

1 عدد CPU fan header\r\n1 عدد water cooling CPU fan header\r\n4 عدد system fan headers\r\n2 عدد system fan/water cooling pump headers\r\n1 عدد CPU cooler LED strip/RGB LED strip header\r\n2 عدد addressable LED strip headers\r\n2 عدد RGB LED strip headers\r\n1 عدد front panel header\r\n1 عدد front panel audio header\r\n1 عدد USB 3.2 Gen 1 header\r\n2 عدد USB 2.0/1.1 headers\r\n2 عدد temperature sensor headers\r\n1 عدد noise detection header\r\n1 عدد Thunderbolt header

WIFI a, b, g, n, ac with wave 2 features, ax, supporting 2.4/5 GHz Dual-Band\r\nBLUETOOTH 5\r\nSupport for 11ax 160MHz wireless standard and up to 2.4 Gbps data rate

High Definition Audio\r\nSupport for DTS:X Ultra\r\n2/4/5.1/7.1-channel\r\nSupport for S/PDIF Out

5 عدد

AMD B550

۴ اسلات DDR4 DIMM sockets supporting up to 128 GB (32 GB single DIMM capacity) of system memory\r\nAMD Ryzen 5000 series Processors:\r\nSupport for DDR4 5100(O.C.) / 5000(O.C.) / 4866(O.C.) / 4600(O.C.) / 4400(O.C.) / 4000(O.C.) / 3600(O.C.) / 3333(O.C.) /3200/2933/2667/2400/2133\r\n3rd Gen AMD Ryzen Processors:\r\nSupport for DDR4 5200(O.C.) / 5000(O.C.) / 4866(O.C.) / 4600(O.C.) / 4400(O.C.) / 4000(O.C.) / 3600(O.C.) / 3333(O.C.) /3200/2933/2667/2400/2133 MHz memory modules\r\n3rd Gen AMD Ryzen with Radeon Graphics processors:\r\nSupport for DDR4 5400(O.C.) / 5200(O.C.) / 5000(O.C.) / 4866(O.C.) / 4600(O.C.) / 4400(O.C.) / 4000(O.C.) / 3600(O.C.) / 3333(O.C.) /3200/2933/2667/2400/2133 MHz memory modules\r\nDual channel memory architecture\r\nSupport for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules\r\nSupport for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules\r\nSupport for Extreme Memory Profile (XMP) memory modules

Q-Flash Plus button

Clear CMOS jumper

2 عدد 256Mbit flash\r\nUse of licensed AMI UEFI BIOS\r\nSupport for DualBIOS\r\nPnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0

Integrated in the 3rd Generation AMD Ryzen with Radeon Graphics processors:\r\n1 عدد HDMI port, supporting a maximum resolution of 4096x2160@60 Hz\r\nMaximum shared memory of 16 GB

1 مسیر PCI Express x16 slot (PCIEX16), integrated in the CPU:\r\n3rd Generation AMD Ryzen processors support PCIe 4.0 x16 mode\r\n3rd Generation AMD Ryzen with Radeon Graphics processors support PCIe 3.0 x16 mode\r\n1 مسیر PCI Express x16 slot (PCIEX4), integrated in the Chipset:\r\nSupporting PCIe 3.0 x4 mode\r\n1 مسیر PCI Express x16 slot (PCIEX2), integrated in the Chipset:\r\nSupporting PCIe 3.0 x2 mode\r\n2 مسیر PCI Express x1 slots

نقاط کنترل ولتاژ

Realtek 2.5GbE LAN chip (2.5 Gbit/1 Gbit/100 Mbit)

Realtek ALC1220-VB codec

شش عدد

کانکتور برق اصلی 24 پبن ATX

PCI-E 3.0 x4

1 مسیر PCI Express x16 slot (PCIEX16)\r\n1 مسیر PCI Express x16 slot (PCIEX4)\r\n1 مسیر PCI Express x16 slot (PCIEX2)

دو عدد
