DDR4 4266(O.C.) / 4133(O.C.) / 4000(O.C.) / 3866(O.C.) / 3800(O.C.) / 3733(O.C.) / 3666(O.C.) / 3600(O.C.) / 3466(O.C.) / 3400(O.C.) / 3333(O.C.) / 3300(O.C.) / 3200(O.C.) / 3000(O.C.) / 2800(O.C.) / 2666 / 2400 / 2133 مگاهرتز

Support for 9th and 8th Generation Intel Core i9 processors/Intel Core i7 processors/Intel Core i5 processors/Intel Core i3 processors/Intel Pentium processors/Intel Celeron processors in the LGA1151 package\r\nL3 cache varies with CPU\r\nIntel Z390 Express Chipset\r\n

دو مسیره

RAID 0

یک عدد برای ماوس

چهار عدد

یک عدد

24 مسیر

DDR4 4266(O.C.) / 4133(O.C.) / 4000(O.C.) / 3866(O.C.) / 3800(O.C.) / 3733(O.C.) / 3666(O.C.) / 3600(O.C.) / 3466(O.C.) / 3400(O.C.) / 3333(O.C.) / 3300(O.C.) / 3200(O.C.) / 3000(O.C.) / 2800(O.C.) / 2666 / 2400 / 2133 MHz memory modules

۱ عدد PS/2 mouse port\r\n۱ عدد PS/2 Keyboard port\r\n۱ عدد HDMI port\r\n۶ عدد USB 3.1 Gen 1 ports\r\n۱ عدد RJ-45 port\r\n۳ عدد audio jacks

۸ عدد USB 3.1 Gen 1 ports (6 ports on the back panel, 2 ports available through the internal USB header)\r\n۲ عدد USB 2.0/1.1 ports available through the internal USB header

۱ عدد M.2 connector (Socket 3, M key, type 2242/2260/2280/22110 SATA and PCIe x4/x2 SSD support)\r\n۶ عدد SATA 6Gb/s connectors\r\nپشتیبانی از RAID 0, RAID 1, RAID 5, and RAID 10\r\nxx Refer to "1-7 Internal Connectors," for the installation notices for the M.2 and SATA connectors xx\r\nIntel Optane Memory Ready

iTE I/O Controller Chip\r\n۱ عدد CPU fan header\r\n۱ عدد system fan headers\r\n۱ عدد RGB LED strip header\r\n۱ عدد front panel header\r\n۱ عدد front panel audio header\r\n۱ عدد USB 3.1 Gen 1 header\r\n۱ عدد USB 2.0/1.1 header\r\n۱ عدد S/PDIF Out header\r\n۱ عدد Thunderbolt add-in card connector\r\n۱ عدد Trusted Platform Module (TPM) header (2x6 pin, for the GC-TPM2.0_S module only)\r\n۱ عدد serial port header

Realtek ALC887 codec\r\nHigh Definition Audio\r\n2/4/5.1/7.1-channel\r\nTo configure 7.1-channel audio, you have to use an HD front panel audio module and enable the multi-channel audio feature through the audio driver\r\nSupport for S/PDIF Out

۴ عدد DDR4 DIMM sockets supporting up to 128GB (32GB single DIMM capacity) of system memory\r\nPlease note that the support for system total memory size depends on the CPU installed\r\nDual channel memory architecture\r\nSupport for DDR4 4266(O.C.) / 4133(O.C.) / 4000(O.C.) / 3866(O.C.) / 3800(O.C.) / 3733(O.C.) / 3666(O.C.) / 3600(O.C.) / 3466(O.C.) / 3400(O.C.) / 3333(O.C.) / 3300(O.C.) / 3200(O.C.) / 3000(O.C.) / 2800(O.C.) / 2666 / 2400 / 2133 MHz memory modules\r\nSupport for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode)\r\nSupport for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules\r\nSupport for Extreme Memory Profile (XMP) memory modules

۱ عدد 128 Mbit flash\r\nUse of licensed AMI UEFI BIOS\r\nPnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0

Onboard Graphics\r\n - Integrated Graphics Processor-Intel HD Graphics support\r\n - ۱ عدد HDMI port, supporting a maximum resolution of 4096x2160@30 Hz\r\n - Support for HDMI 1.4 version and HDCP 2.2\r\n - Maximum shared memory of 1 GB\r\n - Actual support may vary by CPU\r\nMulti-Graphics Technology\r\n - Support for AMD Quad-GPU CrossFire and 2-Way AMD CrossFire technologies

نقاط کنترل ولتاژ

Realtek GbE LAN chip (10/100/1000 Mbit)

Realtek ALC887 codec

شش عدد

کانکتور برق اصلی 24 پبن ATX

PCI-E 3.0 x4

۱ مسیر PCI Express x16 slot, running at x16 (PCIEX16)\r\n۲ مسیر PCI Express x16 slots, running at x4 (PCIEX4_1/PCIEX4_2)\r\n۳ مسیر PCI Express x1 slots

Intel LGA 1151
