DDR4 2666/2400/2133 مگاهرتز

6 فاز

Support for 9th and 8th Generation Intel Core i9 processors/Intel Core i7 processors/Intel Core i5 processors/Intel Core i3 processors/Intel Pentium processors/Intel Celeron processors in the LGA1151 package\r\nL3 cache varies with CPU

16 مسیر

1 عدد PS/2 keyboard/mouse port\r\n1 عدد parallel port (LPT)\r\n1 عدد serial port (VGA)\r\n1 عدد D-Sub port\r\n1 عدد D-Sub port\r\n2 عدد USB 3.1 Gen 1 ports\r\n4 عدد USB 2.0/1.1 ports\r\n1 عدد RJ-45 port\r\n3 عدد audio jacks

4 عدد USB 3.1 Gen 1 ports (2 ports on the back panel, 2 ports available through the internal USB header)\r\n6 عدد USB 2.0/1.1 ports (4 ports on the back panel, 2 ports available through the internal USB header)

1 عدد M.2 connector (Socket 3, M key, type 2242/2260/2280 SATA and PCIe x2 SSD support)4 عدد SATA 6Gb/s connectors

1 عدد CPU fan header\r\n1 عدد system fan headers\r\n1 عدد front panel header\r\n1 عدد front panel audio header\r\n1 عدد S/PDIF Out header\r\n1 عدد USB 3.1 Gen 1 header\r\n1 عدد USB 2.0/1.1 header\r\n1 عدد Trusted Platform Module (TPM) header (2x6 pin, for the GC-TPM2.0_S module only)\r\n

Realtek ALC887 codec\r\nHigh Definition Audio\r\n2/4/5.1/7.1-channel\r\nTo configure 7.1-channel audio, you have to use an HD front panel audio module and enable the multi-channel audio feature through the audio driver\r\nSupport for S/PDIF Out

Intel H370

2 عدد DDR4 DIMM sockets supporting up to 32 GB of system memoryDual channel memory architectureSupport for DDR4 2666/2400/2133 MHz memory modulesSupport for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode)Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modulesSupport for Extreme Memory Profile (XMP) memory modulesTo support 2666 MHz or XMP memory, you must install a 9th or 8th Generation Intel Core i9/i7/i5 processor

1 عدد Clear CMOS jumper

2 عدد 128 Mbit flash\r\nUse of licensed AMI UEFI BIOS\r\nSupport for DualBIOS\r\nPnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0

1 عدد D-Sub port, supporting a maximum resolution of 1920x1200@60 Hz\r\n1 عدد HDMI port, supporting a maximum resolution of 4096x2160@30 Hz\r\n - Support for HDMI 1.4 version and HDCP 2.2\r\nMaximum shared memory of 1GB

1 مسیر PCI Express x16 slot, running at x16 (PCIEX16)\r\n2 مسیر PCI Express x1 slots\r\n3 مسیر PCI slots

نقاط کنترل ولتاژ

Realtek GbE LAN chip (10/100/1000 Mbit)

Realtek ALC887 codec

چهار عدد

PCIE 3.0 X2
