DDR4 2666/2400/2133 مگاهرتز

6 فاز

Support for 9th and 8th Generation Intel® Core™ i9 processors/Intel® Core™ i7 processors/Intel® Core™ i5 processors/ Intel® Core™ i3 processors/Intel® Pentium® processors/Intel® Celeron® processors in the LGA1151 package

Support for 9th and 8th Generation Intel® Core i9 processors/Intel Core i7 processors/Intel® Core i5 processors/ Intel Core i3 processors/Intel Pentium processors/Intel Celeron processors in the LGA1151 package\r\nL3 cache varies with CPU

RAID 0

یک عدد کومبو

چهار عدد

یک عدد

16 مسیر

۱ عدد PS/2 keyboard/mouse port\r\n۱ عدد D-Sub port\r\n۱ عدد DVI-D port\r\n۱ عدد HDMI port\r\n۴ عدد USB 3.1 Gen 1 ports\r\n۲ عدد USB 2.0/1.1 ports\r\n۱ عدد RJ-45 port\r\n۳ عدد audio jacks

۶ عدد USB 3.1 Gen 1 ports (4 ports on the back panel, 2 ports available through the internal USB header)\r\n۶ عدد USB 2.0/1.1 ports (2 ports on the back panel, 4 ports available through the internal USB headers)

۱ عدد M.2 connector (Socket 3, M key, type 2242/2260/2280 SATA and PCIe x4/x2 SSD support)\r\n۶ عدد SATA 6Gb/s connectors\r\nپشتیبانی از RAID 0, RAID 1, RAID 5 and RAID 10\r\nRefer to 1-7 Internal Connectors, for the installation notices for the M.2 and SATA connectors\r\nIntel Optane Memory Ready

۱ عدد USB 3.1 Gen 1 header\r\n۲ عدد USB 2.0/1.1 headers\r\n۱ عدد CPU fan header\r\n۱ عدد RGB LED strip header\r\n۱ عدد front panel header\r\n۱ عدد front panel audio header\r\n۱ عدد S/PDIF Out header\r\n۱ عدد Trusted Platform Module (TPM) header (2x6 pin, for the GC-TPM2.0_S module only)\r\n۱ عدد serial port header\r\n۱ عدد parallel port header\r\n

10/100/1000 Mbit

Realtek ALC887 codec\r\nHigh Definition Audio\r\n2/4/5.1/7.1-channel\r\nTo configure 7.1-channel audio, you have to use an HD front panel audio module and enable the multi-channel audio feature through the audio driver\r\nSupport for S/PDIF Out

6 عدد

۴ عدد DDR4 DIMM sockets supporting up to 64 GB of system memory\r\nDual channel memory architecture\r\nSupport for DDR4 2666/2400/2133 MHz memory modules\r\nSupport for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode)\r\nSupport for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules\r\nSupport for Extreme Memory Profile (XMP) memory modules\r\nTo support 2666 MHz or XMP memory, you must install a 9th and 8th Generation Intel Core i9/i7/i5 processor

1 عدد جامپر Clear CMOS\r\n

۲ عدد 128 Mbit flash\r\nUse of licensed AMI UEFI BIOS\r\nSupport for DualBIOS\r\nPnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0

Integrated Graphics Processor-Intel HD Graphics support\r\n۱ عدد D-Sub port, supporting a maximum resolution of 1920x1200@60 Hz\r\n۱ عدد DVI-D port, supporting a maximum resolution of 1920x1200@60 Hz\r\n - The DVI-D port does not support D-Sub connection by adapter\r\n۱ عدد HDMI port, supporting a maximum resolution of 4096x2160@30 Hz\r\n - Support for HDMI 1.4 version and HDCP 2.2\r\nSupport for up to 3 displays at the same time\r\nMaximum shared memory of 1 GB\r\nActual support may vary by CPU

۱ مسیر PCI Express x16 slot, running at x16\r\n۱ مسیر PCI Express x4 slot\r\n۱ مسیر PCI Express x1 slot

Windows 10 64-bit

microATX

پروفایل حافظه XMP

Realtek ALC887 codec

7.1 کاناله

شش عدد

کانکتور برق اصلی 24 پبن ATX

iTE I/O Controller

PCI-E 3.0 x4

دو عدد
