DDR4 2933/2666/2400/2133 مگاهرتز

پشتیبانی از Support for 10th Generation Intel Core i9 processors/Intel Core i7 processors/Intel Core i5 processors/Intel Core i3 processors/Intel Pentium processors/Intel Celeron processors in the LGA1200 package\r\nL3 cache varies with CPU

۰

۱ عدد M.2 connector (Socket 3, M key, type 2242/2260/2280 SATA and PCIe x2 SSD support)\r\n۴ عدد SATA 6Gb/s connectors\r\nM.2 connectors support up to ASPM L1.2 PCIe power management protocols

۱ عدد 24pin ATX main power connector\r\n۱ عدد 8pin ATX 12V power connector\r\n۴ عدد SATA 6Gb/s connectors\r\n۱ عدد CPU fan header\r\n۱ عدد system fan header\r\n۱ عدد RGB LED strip header\r\n۱ عدد front panel header\r\n۱ عدد front panel audio header\r\n۱ عدد USB 3.2 Gen 1 header\r\n۱ عدد USB 2.0/1.1 header\r\n۱ عدد speaker header\r\n۱ عدد Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0 module only)\r\n۱ عدد serial port header\r\n۱ عدد M.2 Socket 3 connector\r\n

Realtek Audio CODEC\r\nHigh Definition Audio\r\n2/4/5.1/7.1-channel

3 عدد

Intel Core i9/i7 processors:\r\nSupport for DDR4 2933/2666/2400/2133 MHz memory modules\r\nIntel Core i5/i3/Pentium/Celeron processors\r\nSupport for DDR4 2666/2400/2133 MHz memory modules\r\n۲ عدد DDR4 DIMM sockets supporting up to 64 GB (32 GB single DIMM capacity) of system memory\r\nDual channel memory architecture\r\nSupport for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode)\r\nSupport for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules\r\nSupport for Extreme Memory Profile (XMP) memory modules

32 گیگابایت

Clear CMOS jumper\r\niTE I/O Controller Chip

128Mbit flash\r\nUse of licensed AMI UEFI BIOS\r\nPnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0

Integrated Graphics Processor-Intel® HD Graphics support:\r\n۱ عدد D-Sub port, supporting a maximum resolution of 1920x1200@60 Hz\r\n۱ عدد DVI-D port, supporting a maximum resolution of 1920x1200@60 Hz\r\n۱ عدد HDMI port, supporting a maximum resolution of 4096x2160@30 Hz\r\nMaximum shared memory of 512 MB

۱ مسیر PCI Express x16 slot, running at x16\r\n۲ مسیر PCI Express x1 slot\r\nSupports up to ASPM L1.2 power management protocols.

microATX

نقاط کنترل ولتاژ

Realtek GbE LAN chip (1000 Mbit/100 Mbit)

شش عدد

کانکتور برق اصلی 24 پبن ATX

2 عدد

PCI-E 2.0 x2

۱ مسیر PCI Express x16 slot, running at x16 (PCIEX16)\r\nSupports up to ASPM L1.2 power management protocols
