Intel® Core™ i3

6 (COM 1~2 with 5V/12V Power Output on 9 Pins, Jumper) (COM3 with 5V/12V Power Output on 9 Pins, BIOS) (COM4 RJ-11, Only TX/RX, 12V Power Output, Reserved for CDP) (COM5 Reserved for Cash Drawer Port) (COM6 RJ-45, Only TX/RX, 5V Power Output, Reserved for MSR)

SATA 3 (6Gb/s) 2.5 inch SSD 64GB (Max. 2 Optional), Support AHCI

4GB Standard (Max. 64GB), DDR4 2133MT/s, Socket 2 x SODIMM

6 (Rear 6 = USB 3.0 x 6)

Display: 1 x VGA (With Power Output) PS/2 Port: 1 (Reserved for Keyboard or Mouse) LAN: 1 x Gigabit Ethernet, RJ-45 Audio: 1 x Line-out, 1 x Mic-in Power DC-IN: 1 x (4 Pin Connector)

Windows 10 IoT Enterprise

Realtek ALC 269

Adaptor 12V, 5A

Type: 15″ TFT LED Backlight Resolution: 15″ 1024 x 768 Brightness: 15″ 300 cd/m² (typ.) Touch Screen: Projected Capacitive Touch
