260 × 222 × 45 mm

8ch

32Kbps-6Mbps

64Kbps

2xUSB 2.0

≤ 12W

1ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz,1024 × 768/60Hz

1ch, RCA : Linear, 1 KΩ

10ºC to +55 ºC-

When 1080p Lite mode not enabled: 3 MP/1080p/720p/VGA/WD1/4CIF/CIF When 1080p Lite mode enabled: 1080p lite/720p/VGA/WD1/4CIF/CIF

10%to 90%

RJ45 10M/100M self-adaptive Ethernet interface

تا 6 ترابایت

:Main stream :When 1080p Lite mode not enabled For 3 MP stream access: 3 MP/1080p/720p/VGA/WD1/4CIF/CIF@12fps For 1080p stream access: 1080p/720p@12fps; VGA/WD1/4CIF/CIF@25fps (P)/30fps N For 720p stream access: 720p/VGA/WD1/4CIF/CIF@25fps (P)/30fps N :When 1080p Lite mode enabled 1080p lite/720p/VGA/WD1/4CIF/CIF@25fps (P)/30fps N :Sub-stream WD1/4CIF/2CIF@12fps; CIF/QVGA/QCIF@25fps (P)/30fps N

G.711u

1x SATA

12VDC

Video/Video&Audio

1080p25, 1080p30, 720p25, 720p30

3MP,1080p25, 1080p30, 720p25, 720p30 Note: The 3 MP signal input is only available for the first 2 channels of DVR-208Q-F1

2ch up to 1080p resolution

8ch BNC interface : 1.0 Vp-p, 75 Ω, پشتیبانی از کابل کواکسیال

(1ch, RCA (2.0 Vp-p, 1 KΩ

≤ 1kg
