AHD Camera:
1080P@25/30, 720P@25/30fps
Analog Camera Input:
4 Channel, BNC
Audio bit rate:
64Kbps Per Channel
Audio Compression:
AAC(only for the 1st channel), G.711A, G.711U, PCM
Audio Sample Rate:
8KHz, 16 bit Per Channel
Backup Mode:
USB Device/Network
Dimensions:
Compact 1U, 260×236×48mm(10.2"×9.3"×1.9")
HDCVI Camera:
1080P@25/30fps, 720P@50/60fps, 720P@25/30fps
Interface:
1 RJ-45 Port (100M)
Internal HDD:
1 SATA Port, up to 6TB capacity
Interoperability:
ONVIF 16.12, CGI Conformant
IP Camera Input:
4+1, each channel up to 2MP
Main Processor:
Embedded Processor
Max. User Access:
128 users
Multi-screen Display:
When IP extension mode not enabled: 1/4When IP extension mode enabled: 1/4/6
Network Function:
HTTP, HTTPS, TCP/IP, IPv4/IPv6, 3G/4G, UPnP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPoE,DDNS, FTP, Alarm Server, P2P,IP Search (Supports Dahua IP camera, DVR, NVS, etc.)
Operating System:
Embedded LINUX
OSD:
Camera title, Time, Video loss, Camera lock, Motion detection, Recording
Playback Function:
Play, Pause, Stop, Rewind, Fast play, Slow Play, Next File, Previous File, Next Camera, Previous Camera, Full Screen, Repeat, Shuffle, Backup selection, Digital Zoom
Power Consumption(without HDD):
<10W
Record Interval:
1 ~ 60 min (default: 60 min), Pre-record: 1 ~ 30 sec, Post-record: 10 ~ 300 sec
Record Mode:
Manual, Schedule (General, Continuous), MD (Video detection: Motion Detection, Video Loss, Tampering), Alarm, Stop
Record Rate:
Main Stream:1080N/720P/960H/D1/CIF (1~25/30fps)Sub stream:CIF (1~15fps)
Resolution:
1920×1080, 1280×1024, 1280×720
RS485:
1 Port, for PTZ Control
Search Mode:
Time /Date, Alarm, MD and Exact Search (accurate to second)
Smart Phone:
iPhone, iPad, Android
Trigger Events:
Recording, PTZ, Tour, Video Push, Email, FTP, Snapshot, Buzzer and Screen Tips
Two-way Talk:
Reuse audio in/out, RCA
Video Bit Rate:
32Kbps ~ 4096Kbps Per Channel
Video Compression:
H.265+/H.265/H.264+/H.264
Video Detection:
Motion Detection, MD Zones: 396 (22 × 18), Video Loss, Tampering and Diagnosis
