Access Control Lists (ACL):
802.1p Priority, ACL Based on, ACL Statistics, CPU Interface Filtering, DSCP, Ether Type, IPv4/v6 Address, IPv6 Flow Label, IPv6 Traffic Class, MAC Address, Protocol Type, Switch Port, TCP/UDP Port Number, Time-based ACL, Up to 1024 ingress access rules, User Defined Packet Content, VLAN ID
Number of Queues per port:
8
VLAN:
802.1Q Tagged VLAN, 802.1v Protocol VLAN, Asymmetric VLAN, Double VLAN (Q-in-Q), GVRP: Max. 255 dynamic VLANs, ISM VLAN, MAC-based VLAN, Port-based Q-in-Q, Port-based VLAN, Selective Q-in-Q, VLAN Group: • Max. 4094 VLAN, VLAN Translation, VLAN Trunking, Voice VLAN
ابعاد(طول*عرض*ارتفاع)(میلی متر):
228.5x195x44
رابط ها:
2-Port Combo 10/100/1000BASE-T/ SFP, 8-Port 10/100/1000BASE-T
عملکردهای لایه 2:
16K MAC Address Table, 802.1D STP, 802.1s MSTP, 802.1w RSTP, BPDU Filtering, DGS-3000-10TC: Max. 5 groups, 8 ports per group, DGS-3000-24TC: Max. 12 groups, 8 ports per group, DGS-3000-26TC: Max. 13 groups, 8 ports per group, Ethernet Ring Protection Switching (ERPS), Flow Control (802.3x, HOL Blocking Prevention), Jumbo Frame:Up to 12KB, L2 Protocol Tunneling (L2PT), Link Aggregation:Compliant with 802.1AX and 802.3ad, Loopback Detection, Port Mirroring:, Root Restriction, Spanning Tree Protocol, Supports 1 Mirroring group, Supports One-to-One, Many-to-One, Flow-based (ACL) Mirroring
عملکردهای لایه 3:
Default Route, Gratuitous ARP, IPv6 Neighbor Discovery (ND), Support 1024 ARP Entries
فایروال و امنیت دسترسی:
ARP Inspection, ARP Spoofing Prevention, BPDU Attack Protection, Broadcast/Multicast/Unicast Storm Control, D-Link Safeguard Engine, DHCP Client Filtering, DHCP Server Screening, DoS Attack Prevention, IP Inspection, IP Source Guard, IP-MAC-Port Binding, L3 Control Packet Filtering, NetBIOS/NetBEUI Filtering, Port Security Up to 64 MAC addresses per port, SSH v1/v2, SSL v1/v2/v3, Traffic Segmentation
گواهی نامه ها:
IPv6 Ready Logo Phase 2
مدیریت:
System Log, Telnet Server, TFTP Client, 802.1AB LLDP – LLDP-MED, BootP/DHCP Client, Command Line Interface (CLI), Command Logging, CPU Monitoring, Debug command, DHCP Auto Configuration, DHCP Client, DHCP Client Option 12, DHCP Relay (Supports IPv4), DHCP Relay options 60, 61, 82, DHCP Server, Flash File System, FTP Client, FTP Client (Supports IPv4/v6), Memory Monitoring, Microsoft® NLB (Network Load Balancing) Support, Multiple Images, NTP, Password Encryption, Password Recovery, Ping (Supports IPv4/v6), PPPoE Circult-ID Tag Insertion, RMONv1, RMONv2, SMTP, SNMP Trap, SNMP Traps, SNMP v1/v2c/v3, SNMP:Supports v1/v2c/v3, Supports 1,2,3,9 groups, Supports Probe Config group, Telnet Client, Traceroute, Traffic Monitoring, Web-based GUI (Supports IPv4/IPv6), ZModem
منبع تغذیه:
100 to 240 V, 50/60 Hz
