4600(OC)/4400(OC)/4266(OC)/4000(OC)/3733(OC)/3600(OC)/3466(OC)/3333(OC)/3200(OC)/2933/2800/2666/2400/2133 مگاهرتز

8 فاز

Intel Socket LGA1200 for 11th Gen Intel Core Processors & 10th Gen Intel Core, Pentium Gold and Celeron Processors\r\nSupports Intel 14nm CPU\r\nSupports Intel Turbo Boost Technology 2.0 and Intel Turbo Boost Max Technology 3.0\r\nIntel Turbo Boost Max Technology 3.0 support depends on the CPU types

یک عدد کومبو

چهار عدد

یک عدد

20 مسیر

DDR4 4OC)/4400(OC)/4266(OC)/4000(OC)/3733(OC)/3600(OC)/3466(OC)/3333(OC)/3200(OC)/2933/2800/2666/2400/2133 MHz Non-ECC, Un-buffered memory

۱ عدد DP port\r\n۱ عدد HDMI port\r\n۲ عدد D-Sub port\r\n3 عدد Audio jack\r\n۱ عدد PS/2 Keyboard/Mouse combo port\r\n۱ عدد Intel I219-V 1Gb Ethernet port\r\n4 عدد USB 2.0 ports (4 x Type-A)\r\n2 عدد USB 3.2 Gen 2 ports (2 x Type-A)\r\n1عدد USB 3.2 Gen 1 port (1 x USB Type-C)\r\n

پنل پشتی:\r\n - ۲ عدد USB 3.2 Gen 2 ports (2 x Type-A)\r\n - ۱ عدد USB 3.2 Gen 1 port (1 x USB Type-C)\r\n - ۴ عدد USB 2.0 ports\r\nاتصالات داخلی:\r\n۱ عدد USB 3.2 Gen 1 header supports additional 2 USB 3.2 Gen 1 ports\r\n۲ عدد USB 2.0 headers support additional 4 USB 2.0 ports

Intel 11th Gen Processors\r\n- M.2_1 slot (Key M) type 2242/2260/2280/22110 (supports PCIE 4.0 x 4 )\r\n- Only Intel 11th processors support PCIe 4.0 x4 mode, this slot will be disabled for other CPUs\r\nIntel B560 Chipset\r\n- M.2_2 slot (Key M) type 2242/2260/2280/22110 (supports PCIE 3.0 x 4 & SATA mode modes)\r\n۶ عدد SATA 6Gb/s port\r\nWhen a device in SATA mode is installed on the M.2_2 socket, SATA6G_2 port cannot be used

۱ عدد TB Header (for add-on TB card)\r\n۱ عدد 4pin CPU Fan header\r\n۳ عدد 4pin Chassis Fan headers\r\n۲ عدد M.2 slots (Key M)\r\n۶ عدد SATA 6Gb/s ports\r\n۱ عدد M.2 slot only (Key E, CNVi & PCIe\r\n۱ عدد USB 3.2 Gen 1 header supports additional 2 USB 3.2 Gen 1 ports\r\n۲ عدد USB 2.0 headers support additional 4 USB 2.0 ports\r\n۲ عدد AURA Addressable Gen 2 header\r\n۲ عدد AURA RGB header\r\n۱ عدد Front Panel Audio header (AAFP)\r\n۱ عدد COM Port header\r\n۱ عدد S/PDIF out header\r\n۱ عدد 20/3pin System Panel header with Chassis intrude function\r\n۱ عدد SPI TPM header (14-1 pin)\r\n۱ عدد Thunderbolt 4 header\r\n\r\n\r\n

M.2 slot only (Key E, CNVi & PCIe)

Jack-detection, Multi-streaming, Front Panel Jack-retasking\r\n- Supports up to 24-Bit/192kHz playback\r\nAudio Features\r\n- Audio Shielding\r\n- Premium Japanese audio capacitors\r\n- Dedicated audio PCB layers\r\nA chassis with an HD audio module in the front panel is required to support 7.1-channel audio output

Memory Channels:4DDR4 (Dual channel)\r\nMax Memory Size:128GB\r\n4600(OC)/4400(OC)/4266(OC)/4000(OC)/3733(OC)/3600(OC)/3466(OC)/3333(OC)/3200(OC)/2933/2800/2666/2400/2133 MHz Non-ECC, Un-buffered memory\r\nDual channel memory architecture\r\nSupports Intel Extreme Memory Profile (XMP)\r\nASUS OptiMem\r\n11th Gen Intel processors support 2933/2800/2666/2400/2133 natively\r\n10th Gen Intel Core i7/i9 processors support 2933/2800/2666/2400/2133 MHz natively, others will run at the maximum transfer rate of DDR4 2666MHz\r\n

۱ عدد Clear CMOS jumper

128Mb Flash ROM, UEFI AMI BIOS\r\n

1 مسیر PCIe 4.0/3.0 x16 slot\r\n1 مسیر PCIe 3.0 x16 slot (supports x4 mode)

1 مسیر PCIe 4.0/3.0 x16 slot\r\n1 مسیر PCIe 3.0 x16 slot (supports x4 mode)\r\n2 مسیر PCIe 3.0 x1 slots

نقاط کنترل ولتاژ

Intel I219-V 1Gb Ethernet port

Realtek ALC897 7.1-Channel High Definition Audio CODEC

دو عدد

شش عدد

کانکتور برق اصلی 24 پبن ATX

WOL by PME, PXE

PCI-E 3.0 x4

1 مسیر PCIe 4.0/3.0 x16 slot\r\n1 مسیر PCIe 3.0 x16 slot (supports x4 mode)\r\n

Intel LGA 1200
