AHD Camera:
5MP, 4MP, 3MP, 1080P@25/30, 720P@25/30fps
Analog Camera Input:
8 Channel, BNC
Audio bit rate:
64Kbps Per Channel
Audio Compression:
AAC(only for the 1st channel), G.711A, G.711U, PCM
Audio Sample Rate:
8KHz, 16 bit Per Channel
Backup Mode:
USB Device/Network
Bit Rate:
32Kbps ~ 6144Kbps Per Channel
Compression:
H.265+/H.265/H.264+/H.264
Dimensions:
Compact 1U, 260×236×48mm(10.2"×9.3"×1.9")
HDCVI Camera:
4K, 6MP, 5MP, 4MP, 1080P@25/30fps, 720P@50/60fps, 720P@25/30fps
Interface:
1 RJ-45 Port (1000M)
Internal HDD:
1 SATA Port, up to 10TB capacity
Interoperability:
ONVIF 16.12, CGI Conformant
IP Camera Input:
8+4 Channel, each channel up to 8MP
Main Processor:
Embedded Processor
Max. User Access:
128 users
Multi-screen Display:
When IP extension mode not enabled: 1/4/8/9When IP extension mode enabled: 1/4/8/9/16
Network Function:
HTTP, HTTPS, TCP/IP, IPv4/IPv6, Wi-Fi, 3G/4G, UPnP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPoE,DDNS, FTP, Alarm Server, P2P,IP Search (Supports Dahua IP camera, DVR, NVS, etc.)
Operating System:
Embedded LINUX
OSD:
Camera title, Time, Video loss, Camera lock, Motion detection, Recording
Playback Function:
Play, Pause, Stop, Rewind, Fast play, Slow Play, Next File, Previous File, Next Camera, Previous Camera, Full Screen, Repeat, Shuffle, Backup selection, Digital Zoom
Power Consumption(without HDD):
<10W
Record Interval:
1 ~ 60 min (default: 60 min), Pre-record: 1 ~ 30 sec, Post-record: 10 ~ 300 sec
Record Mode:
Manual, Schedule (General, Continuous), MD (Video detection: Motion Detection, Video Loss, Tampering), Alarm, Stop
Record Rate:
Main stream: 4K(1~7fps); 6MP(1~10fps); 5MP(1~12fps); 4MP/3MP(1~15fps); 4M-N/1080P/720P/960H/D1/CIF(1~25/30fps)Sub stream:960H(1~15fps);D1/CIF(1~25/30fps)
Resolution:
HDMI:3840×2160, 2560×1440, 1920×1080, 1280×1024, 1280×720VGA: 1920×1080, 1280×1024, 1280×720
RS485:
1 Port, for PTZ Control
Search Mode:
Time /Date, Alarm, MD and Exact Search (accurate to second)
Smart Phone:
iPhone, iPad, Android
Trigger Events:
Recording, PTZ, Tour, Video Push, Email, FTP, Snapshot, Buzzer and Screen Tips
Two-way Talk:
Reuse audio in/out, RCA
USB:
2 USB Ports (1 USB 2.0,1 USB 3.0)
Video Detection:
Motion Detection, MD Zones: 396 (22 × 18), Video Loss,Tampering and Diagnosis
